• Blue Sea Systems 5032; Fuse Block ST Blade Split bus 12 Circuit

Blue Sea Systems 5032; Fuse Block ST Blade Split bus 12 Circuit

    • MPN: 5032
    • SKU : LNS-661-5032
    • List Price: $102.89
      Price: $97.89
      You Save: $5.00 (5%)
    • Cross Ship:35 At Manufacturer (Received by us in 2 days , then ships to you)
ESTIMATE SHIPPING: Add parts, then click "My Cart" at top of screen to see "Estimate Shipping Charges & Processing Times" tool.

Description:

Fuse Block ST Blade Split bus 12 Circuit

Two isolated 6-circuit fuse blocks with a negative bus. For use when a mix of switched and 24-hour circuits are desired in the same block

Features:
  • Common and/or independent source fuse block

  • Provides two isolated groups of six ATO®/ATC® circuits

  • For use with either two isolated batteries or with a single battery providing a mix of 24-hour and switched circuits

  • Clear insulating cover satisfies ABYC/USCG insulation requirements and provides storage for two spare fuses

  • Accepts ring terminals

  • Easy to open, push button latch provides easy access to fuses

  • Tin-plated copper buses and fuse clips

  • Includes 20 write-on circuit labels

  • Fuses sold separately

Specifications
  • Voltage Max. Operating: 32V DC

  • Amperage Max. Operating: 30A per circuit 100A total (not to exceed 80A per load group)

  • Fuse Type: ATO® or ATC® Fuses

  • Screw Terminal: #8-32 Screws with captive star lock washer

  • Mounting: #8 Screw (M4)

  • Recommended Wire Size: Positive Feed: 4-6 AWG (25-16 mm²), Branck Circuits: 10-16 AWG (6-15 mm²)

  • Recommended Torque: #10 Stud: 24 in-lb (2.71 N-m), #8 Screw: 18 in-lb (2.03 N-m)
