2009 Outboard 25hp - F25LA ELECTRICAL 4 diagram
-20%
1
Yamaha Motors
RELAY ASSY63P-W8195-00-00
Required: 1
RELAY ASSY
Supersedes: 63P-81950-00-00
In stock
5+ in stock
$391.95
You save $98.04
-15%
2
Yamaha Motors
BOLT97095-06020-00
Required: 2
BOLT
Supersedes: 97075-06020-00
No longer availableSearch Nationwide Inventory
$3.82
You save $0.68
-20%
3
Yamaha Motors
Plate Washer92990-06600-00
Required: 2
WASHER
Supersedes: 92995-06600-00
In stock
5+ in stock
$2.36
You save $0.59
-15%
$6.37
You save $1.12
-15%
5
Yamaha Motors
Tapping Screw90167-05009-00
Required: 2
SCREW, TAPPING
$2.76
You save $0.49
-15%
No longer availableSearch Nationwide Inventory
$23.79
You save $4.20
-15%
7
Yamaha Motors
Terminal Cap6P2-8183X-00-00
Required: 2
CAP, TERMINAL
$5.94
You save $1.05
-15%
No longer availableSearch Nationwide Inventory
$5.09
You save $0.90
-20%
9
Yamaha Motors
Spring Washer92995-06100-00
Required: 2
WASHER, SPRING
In stock
5+ in stock
$2.84
You save $0.71
-20%
10
Yamaha Motors
Plate Washer92990-06600-00
Required: 2
WASHER
Supersedes: 92995-06600-00
In stock
5+ in stock
$2.36
You save $0.59
-15%
No longer availableSearch Nationwide Inventory
$2.68
You save $0.47
-20%
12
Yamaha Motors
Clamp90465-10098-00
Required: 1
CLAMP
Supersedes: 90465-11M10-00
In stock
5+ in stock
$2.24
You save $0.56
-15%
$5.52
You save $0.97
-20%
In stock
5+ in stock
$2.21
You save $0.55
-20%
15
Yamaha Motors
Plate Washer92990-06600-00
Required: 1
WASHER
Supersedes: 92995-06600-00
In stock
5+ in stock
$2.36
You save $0.59
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
