2008 Snowmobile RFX10RSA - RFX10RSA (8HB3) [020] STEERING GATE diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status

Click on

to see part

Ships Now

Ships Later

Out of Stock

Yamaha Motors RFX10RSA (8HB3) [020] - STEERING GATE

Change View:

-15%

Yamaha Motors

STEERING GATE COMPLETE8GL-23870-01-00

Required: 1

STEERING GATE COMP.

Supersedes: 8GL-23870-00-00

No longer availableSearch Nationwide Inventory

~~$363.99~~

$309.39

You save $54.60

-15%

. CLAMP

~~$8.49~~

$7.22

You save $1.27

More details

-15%

Yamaha Motors

Fuel Cam Shaft Stopper8FA-24768-00-00

Required: 2

. STOPPER

~~$7.49~~

$6.37

You save $1.12

More details

-15%

Yamaha Motors

Flange Bolt95822-08035-00

Required: 4

BOLT, FLANGE

~~$4.50~~

$3.82

You save $0.68

More details

-15%

Yamaha Motors

Flange Nut95702-08500-00

Required: 4

NUT, WITH WASHER

In stock

Only 2 remaining

~~$1.05~~

$0.89

You save $0.16

More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
