1989 Snowmobile SV80 - SV80 (85X1) [020] FRAME diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status

Click on

to see part

Ships Now

Ships Later

Out of Stock

Change View:

-15%

Yamaha Motors

85H-21910-11-0085G-21910-01-00

Required: 1

FRAME COMP.

No longer availableSearch Nationwide Inventory

~~$386.99~~

$328.94

You save $58.05

More details

-15%

Yamaha Motors

Front Bupber85G-77511-08-00

Required: 1

.BUMPER, front 1

No longer availableSearch Nationwide Inventory

~~$86.90~~

$73.86

You save $13.03

-20%

.BOLT, with washer

Supersedes: 97522-08640-00

In stock

5+ in stock

~~$8.49~~

$6.79

You save $1.70

More details

-15%

Yamaha Motors

Grommet90480-13163-00

Required: 1

GROMMET

~~$7.99~~

$6.79

You save $1.20

More details

-15%

Yamaha Motors

TOOL KIT85G-28100-00-00

Required: 1

TOOL KIT

No longer availableSearch Nationwide Inventory

~~$26.99~~

$22.94

You save $4.05

More details

-15%

Yamaha Motors

3Y6-85130-01-003Y6-85130-00-00

Required: 1

REAR REFLECTOR ASSY

Supersedes: 3Y6-85130-01-00

~~$18.99~~

$16.14

You save $2.85

More details

-15%

Yamaha Motors

95707-05500-0095701-05500-00

Required: 1

NUT, flange

No longer availableSearch Nationwide Inventory

~~$2.75~~

$2.34

You save $0.41

More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
