2009 Scooter AL115 - AL115 (5WR7) [010] FLASHER LIGHT diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status

Click on

to see part

Ships Now

Ships Later

Out of Stock

Change View:

Yamaha Motors

FRONT FLASHER LIGHT ASSY 128D-H3301-00

Required: 1

FRONT FLASHER LIGHT ASSY 1

Price unavailable

Yamaha Motors

. BULB, FLASHER (12V-10W)5HV-H3311-00

Required: 2

. BULB, FLASHER (12V-10W)

Price unavailable

Yamaha Motors

. BULB (12V-5W)5YP-H5353-00

Required: 2

. BULB (12V-5W)

Price unavailable

Yamaha Motors

. LENS, FLASHER28D-H3312-00

Required: 1

. LENS, FLASHER

Price unavailable

Yamaha Motors

. SOCKET CORD ASSY28D-H4140-00

Required: 1

. SOCKET CORD ASSY

Price unavailable

-15%

SCREW, TRUSS HEAD TAPPING

In stock

Only 4 remaining

~~$1.85~~

$1.57

You save $0.28

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
