2003 Scooter YP180E - YP180E (5XM2) [010] TRANSMISSION diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status

Click on

to see part

Ships Now

Ships Later

Out of Stock

Yamaha Motors YP180E (5XM2) [010] - TRANSMISSION

Change View:

Yamaha Motors

MAIN AXLE COMP.5KD-E7410-00

Required: 1

MAIN AXLE COMP.

Price unavailable

Yamaha Motors

WASHER, PLATE90201-15X01

Required: 2

WASHER, PLATE

Price unavailable

Yamaha Motors

BEARING93311-315Y4

Required: 1

BEARING

Price unavailable

Yamaha Motors

AXLE, DRIVE5NS-E7421-00

Required: 1

AXLE, DRIVE

Price unavailable

Yamaha Motors

GEAR, 1ST WHEEL5KD-E7211-00

Required: 1

GEAR, 1ST WHEEL

Price unavailable

-15%

Yamaha Motors

Circle Clip99009-25400-00

Required: 1

CIRCLIP

~~$9.49~~

$8.07

You save $1.42

More details

Yamaha Motors

BEARING93306-303X2

Required: 1

BEARING

Price unavailable

Yamaha Motors

BEARING93306-272Y1

Required: 1

BEARING

Price unavailable

-15%

Yamaha Motors

SD-TYPE OIL SEAL93102-32298-00

Required: 1

OIL SEAL

~~$18.49~~

$15.72

You save $2.77

More details

Yamaha Motors

BEARING93306-301X9

Required: 1

BEARING

Price unavailable

-15%

Yamaha Motors

Bearing93306-20327-00

Required: 1

BEARING

Supersedes: 93306-203YC-00

~~$42.99~~

$36.54

You save $6.45

More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
