2003 Scooter YP180E - YP180E (5XM2) [060] CRANKSHAFT & PISTON diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors YP180E (5XM2) [060] - CRANKSHAFT & PISTON
Change View:
CRANKSHAFT ASSY
1
Yamaha Motors
CRANKSHAFT ASSY5XM-E1400-00
Required: 1
CRANKSHAFT ASSY
Price unavailable
. SPACER
3
Yamaha Motors
. SPACER3UH-E1445-00
Required: 1
. SPACER
Price unavailable
. GEAR, PUMP DRIVE
4
Yamaha Motors
. GEAR, PUMP DRIVE5DS-E3324-00
Required: 1
. GEAR, PUMP DRIVE
Price unavailable
. FILTER,ROTARY
5
Yamaha Motors
. FILTER,ROTARY5DS-13451-00
Required: 1
. FILTER,ROTARY
Price unavailable
-15%
Woodruff Key
6
Yamaha Motors
Woodruff Key90280-03017-00
Required: 1
KEY, WOODRUFF
Supersedes: 90280-03045-00
1 aftermarket alternative
Cross Ship
Leaves in 2-5 days
$8.49
$7.22
You save $1.27
More details
PISTON (STD)
7
Yamaha Motors
PISTON (STD)5XM-E1631-00
Required: 1
PISTON (STD)
Price unavailable
PISTON (0.25MM O/S)
7
Yamaha Motors
PISTON (0.25MM O/S)5XM-E1635-00
Required: 1
PISTON (0.25MM O/S)
Price unavailable
PISTON (0.50MM O/S)
7
Yamaha Motors
PISTON (0.50MM O/S)5XM-E1636-00
Required: 1
PISTON (0.50MM O/S)
Price unavailable
PIN, PISTON
8
Yamaha Motors
PIN, PISTON5XM-E1633-00
Required: 1
PIN, PISTON
Price unavailable
CIRCLIP
9
Yamaha Motors
CIRCLIP93450-16X01
Required: 2
CIRCLIP
Price unavailable
PISTON RING SET (STD)
10
Yamaha Motors
PISTON RING SET (STD)5XM-E1603-00
Required: 1
PISTON RING SET (STD)
Price unavailable
PISTON RING SET (0.25MM O/S)
10
Yamaha Motors
PISTON RING SET (0.25MM O/S)5XM-E1604-00
Required: 1
PISTON RING SET (0.25MM O/S)
Price unavailable
PISTON RING SET (0.50MM O/S)
10
Yamaha Motors
PISTON RING SET (0.50MM O/S)5XM-E1605-00
Required: 1
PISTON RING SET (0.50MM O/S)
Price unavailable

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
