2003 Scooter CW50RS - CW50RS (1B01) [070] FRONT FENDER diagram
![Yamaha Motors CW50RS (1B01) [070] - FRONT FENDER](https://cdn.crowleymarine.com/yamaha/zQtrawEG.png)
1
Yamaha Motors
FENDER, FRONT5FX-F1511-00-P9
Required: 1
FENDER, FRONT
Price unavailable
2
Yamaha Motors
MOLE, FENDER5FX-F1519-10-P0
Required: 1
MOLE, FENDER
Price unavailable
3
Yamaha Motors
SCREW, TAPPING90167-05X04
Required: 2
SCREW, TAPPING
Price unavailable
-15%
$8.92
You save $1.57
5
Yamaha Motors
WASHER, PLATE90202-05X00
Required: 2
WASHER, PLATE
Price unavailable
-15%
6
Yamaha Motors
Spring Nut90183-05X03-00
Required: 2
NUT, SPRING
Supersedes: 90183-05X00-00
No longer availableSearch Nationwide Inventory
$7.22
You save $1.27
7
Yamaha Motors
FENDER, INNER5FX-F1552-00
Required: 1
FENDER, INNER
Price unavailable
8
Yamaha Motors
FENDER, INNER 24SB-F1553-00
Required: 1
FENDER, INNER 2
Price unavailable
-15%
9
Yamaha Motors
Flange Bolt95817-06010-00
Required: 1
BOLT, FLANGE
Supersedes: 95807-06010-00
In stock
Only 1 remaining
$4.67
You save $0.82
-15%
10
Yamaha Motors
90119-06060-0090119-06052-00
Required: 2
BOLT, WITH WASHER
No longer availableSearch Nationwide Inventory
$2.25
You save $0.40
11
Yamaha Motors
GRAPHIC 25NU-F1579-00
Required: 1
GRAPHIC 2
Price unavailable
12
Yamaha Motors
EMBLEM, YAMAHAX01-F153A-10
Required: 1
EMBLEM, YAMAHA
Price unavailable
13
Yamaha Motors
FENDER, OVER5FX-F1551-00-P5
Required: 1
FENDER, OVER
Price unavailable
-15%
14
Yamaha Motors
Tapping Screw90167-05X01-00
Required: 2
SCREW, TAPPING
No longer availableSearch Nationwide Inventory
$3.53
You save $0.62
15
Yamaha Motors
GUARD, MUD4SB-F1629-01
Required: 1
GUARD, MUD
Price unavailable
-15%
16
Yamaha Motors
Spring Nut90183-05X03-00
Required: 2
NUT, SPRING
Supersedes: 90183-05X00-00
No longer availableSearch Nationwide Inventory
$7.22
You save $1.27
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
