2001 Scooter CY50R - CY50R (3WG9) [010] FRONT FORK diagram
![Yamaha Motors CY50R (3WG9) [010] - FRONT FORK](https://cdn.crowleymarine.com/yamaha/87n59ucK.png)
1
Yamaha Motors
FRONT FORK ASSY (L.H)4CX-F3102-00-33
Required: 1
FRONT FORK ASSY (L.H)
Price unavailable
2
Yamaha Motors
. INNER TUBE COMP.14CX-F3110-00
Required: 1
. INNER TUBE COMP.1
Price unavailable
3
Yamaha Motors
. OUTER TUBE COMP.4CX-F3106-00-33
Required: 1
. OUTER TUBE COMP.
Price unavailable
4
Yamaha Motors
. SPRING, REBOUND4CX-F3151-00
Required: 1
. SPRING, REBOUND
Price unavailable
5
Yamaha Motors
. COLLAR4CX-F3113-00
Required: 1
. COLLAR
Price unavailable
6
Yamaha Motors
. METAL, SLIDE 14CX-F3125-00
Required: 1
. METAL, SLIDE 1
Price unavailable
-15%
No longer availableSearch Nationwide Inventory
$0.93
You save $0.16
8
Yamaha Motors
. SPRING, FRONT FORK4CX-F3141-00
Required: 1
. SPRING, FRONT FORK
Price unavailable
9
Yamaha Motors
. RUBBER4CX-F3195-00
Required: 1
. RUBBER
Price unavailable
10
Yamaha Motors
. SEAT, SPRING LOWER4CX-F3143-00
Required: 1
. SEAT, SPRING LOWER
Price unavailable
11
Yamaha Motors
. SEAL, DUST4CX-F3144-00
Required: 1
. SEAL, DUST
Price unavailable
12
Yamaha Motors
. CAP4CX-F3154-00
Required: 1
. CAP
Price unavailable
13
Yamaha Motors
FRONT FORK ASSY (R.H)4CX-F3103-00-33
Required: 1
FRONT FORK ASSY (R.H)
Price unavailable
14
Yamaha Motors
. INNER TUBE COMP.14CX-F3110-00
Required: 1
. INNER TUBE COMP.1
Price unavailable
15
Yamaha Motors
. OUTER TUBE COMP.4CX-F3107-00-33
Required: 1
. OUTER TUBE COMP.
Price unavailable
16
Yamaha Motors
. SPRING, REBOUND4CX-F3151-00
Required: 1
. SPRING, REBOUND
Price unavailable
17
Yamaha Motors
. COLLAR4CX-F3113-00
Required: 1
. COLLAR
Price unavailable
18
Yamaha Motors
. METAL, SLIDE 14CX-F3125-00
Required: 1
. METAL, SLIDE 1
Price unavailable
-15%
No longer availableSearch Nationwide Inventory
$0.93
You save $0.16
20
Yamaha Motors
. SPRING, FRONT FORK4CX-F3141-00
Required: 1
. SPRING, FRONT FORK
Price unavailable
21
Yamaha Motors
. RUBBER4CX-F3195-00
Required: 1
. RUBBER
Price unavailable
22
Yamaha Motors
. SEAT, SPRING LOWER4CX-F3143-00
Required: 1
. SEAT, SPRING LOWER
Price unavailable
23
Yamaha Motors
. SEAL, DUST4CX-F3144-00
Required: 1
. SEAL, DUST
Price unavailable
24
Yamaha Motors
. CAP4CX-F3154-00
Required: 1
. CAP
Price unavailable
25
Yamaha Motors
. BOOT4CX-F3191-00
Required: 1
. BOOT
Price unavailable
26
Yamaha Motors
. CLAMP90464-13804
Required: 1
. CLAMP
Price unavailable
27
Yamaha Motors
UNDER BRACKET COMP.4CX-F3340-00
Required: 1
UNDER BRACKET COMP.
Price unavailable
28
Yamaha Motors
BOLT, FLANGE9582L-10030
Required: 2
BOLT, FLANGE
Price unavailable
29
Yamaha Motors
RING, SNAP4CX-F3153-00
Required: 2
RING, SNAP
Price unavailable
30
Yamaha Motors
RACE, BALL 41TK-F3414-01
Required: 1
RACE, BALL 4
Price unavailable
31
Yamaha Motors
RACE, BALL 13WG-F3411-00
Required: 1
RACE, BALL 1
Price unavailable
-15%
32
Yamaha Motors
Ball Race2SA-23412-00-00
Required: 1
RACE, BALL 2
Supersedes: 2E9-23412-00-00
$28.89
You save $5.10
-15%
33
Yamaha Motors
Ball Race2SA-23413-00-00
Required: 1
RACE, BALL 3
Supersedes: 2E9-23413-01-00
$28.89
You save $5.10
-15%
In stock
Only 4 remaining
$2.46
You save $0.44
35
Yamaha Motors
NUT, FITTING 21TK-F3454-00
Required: 1
NUT, FITTING 2
Price unavailable
36
Yamaha Motors
HOLDER, CABLE4CX-F3317-00
Required: 1
HOLDER, CABLE
Price unavailable
37
Yamaha Motors
HOLDER, BRAKE HOSE 14CX-F5875-00
Required: 1
HOLDER, BRAKE HOSE 1
Price unavailable
-15%
38
Yamaha Motors
Bind Screw98907-06010-00
Required: 2
SCREW, BIND
Supersedes: 9890L-06010-00
$1.53
You save $0.27
39
Yamaha Motors
REFLECTOR, FRONT 14SJ-H5111-00
Required: 1
REFLECTOR, FRONT 1
Price unavailable
40
Yamaha Motors
REFLECTOR, FRONT 14SJ-H5111-00
Required: 1
REFLECTOR, FRONT 1
Price unavailable
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
