2001 Scooter CW50RS - CW50RS (5FXM) [030] CYLINDER diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status

Click on

to see part

Ships Now

Ships Later

Out of Stock

Yamaha Motors CW50RS (5FXM) [030] - CYLINDER

Change View:

Yamaha Motors

HEAD, CYLINDER 15FX-E1111-00

Required: 1

HEAD, CYLINDER 1

Price unavailable

-15%

Yamaha Motors

Cylinder Head Gasket3VL-E1181-00-00

Required: 1

GASKET, CYLINDER HEAD 1

~~$21.99~~

$18.69

You save $3.30

More details

Yamaha Motors

PLUG, SPARK94701-00195

Required: 1

PLUG, SPARK

Price unavailable

Yamaha Motors

CYLINDER 15FX-E1311-00

Required: 1

CYLINDER 1

Price unavailable

-15%

Yamaha Motors

Cylinder Gasket3VL-E1351-00-00

Required: 1

GASKET, CYLINDER

~~$11.49~~

$9.77

You save $1.72

More details

-15%

Yamaha Motors

Stud Bolt90116-06418-00

Required: 4

BOLT, STUD

~~$10.49~~

$8.92

You save $1.57

More details

-15%

Yamaha Motors

Flange Nut95707-06500-00

Required: 4

NUT, FLANGE

~~$1.00~~

$0.85

You save $0.15

More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
