All diagrams for this model

2000 Scooter YP125E - YP125E (5DSC) [010] HEADLIGHT diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors YP125E (5DSC) [010] - HEADLIGHT
Change View:
HEADLIGHT UNIT ASSY
1
Yamaha Motors
HEADLIGHT UNIT ASSY5DS-H4310-00
Required: 1
HEADLIGHT UNIT ASSY
Price unavailable
. HEADLIGHT UNIT ASSY
2
Yamaha Motors
. HEADLIGHT UNIT ASSY5DS-H4103-00
Required: 1
. HEADLIGHT UNIT ASSY
Price unavailable
. REFLECTOR
3
Yamaha Motors
. REFLECTOR5DS-H4323-00
Required: 1
. REFLECTOR
Price unavailable
. SOCKET
4
Yamaha Motors
. SOCKET5DU-H4112-00
Required: 2
. SOCKET
Price unavailable
. BULB, HEADLIGHT
5
Yamaha Motors
. BULB, HEADLIGHT5AD-H4314-00
Required: 2
. BULB, HEADLIGHT
Price unavailable
. SPRING, REFLECTOR
6
Yamaha Motors
. SPRING, REFLECTOR3WG-H4324-00
Required: 2
. SPRING, REFLECTOR
Price unavailable
. SPRING, SCREW
7
Yamaha Motors
. SPRING, SCREW5AD-H4332-00
Required: 1
. SPRING, SCREW
Price unavailable
. SCREW, PAN HEAD
8
Yamaha Motors
. SCREW, PAN HEAD90157-04X02
Required: 1
. SCREW, PAN HEAD
Price unavailable
HOLDER, SOCKET
9
Yamaha Motors
HOLDER, SOCKET5DS-H4312-00
Required: 1
HOLDER, SOCKET
Price unavailable
SCREW, TAPPING
10
Yamaha Motors
SCREW, TAPPING90167-04X00
Required: 4
SCREW, TAPPING
Price unavailable
PILOT LIGHT ASSY
11
Yamaha Motors
PILOT LIGHT ASSY4SB-H3530-00
Required: 1
PILOT LIGHT ASSY
Price unavailable
. BULB
12
Yamaha Motors
. BULB3WW-H4347-00
Required: 1
. BULB
Price unavailable
. SOCKET, PILOT LIGHT
13
Yamaha Motors
. SOCKET, PILOT LIGHT3UP-H4346-00
Required: 1
. SOCKET, PILOT LIGHT
Price unavailable
SCREW, TAPPING
14
Yamaha Motors
SCREW, TAPPING90167-04X00
Required: 2
SCREW, TAPPING
Price unavailable

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
