2000 Scooter YN50 - YN50 (5BX5) [010] HEADLIGHT diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors YN50 (5BX5) [010] - HEADLIGHT
Change View:
HEADLIGHT UNIT ASSY
1
Yamaha Motors
HEADLIGHT UNIT ASSY5AD-H4310-00
Required: 1
HEADLIGHT UNIT ASSY
Price unavailable
. HEADLIGHT UNIT ASSY
2
Yamaha Motors
. HEADLIGHT UNIT ASSY5AD-H4103-00
Required: 1
. HEADLIGHT UNIT ASSY
Price unavailable
. HOLDER, SOCKET
3
Yamaha Motors
. HOLDER, SOCKET3WG-H4312-00
Required: 1
. HOLDER, SOCKET
Price unavailable
. BULB, HEADLIGHT
4
Yamaha Motors
. BULB, HEADLIGHT5AD-H4314-00
Required: 1
. BULB, HEADLIGHT
Price unavailable
. SPRING, REFLECTOR
5
Yamaha Motors
. SPRING, REFLECTOR3WG-H4324-00
Required: 1
. SPRING, REFLECTOR
Price unavailable
. NUT, BODY FITTING
6
Yamaha Motors
. NUT, BODY FITTING5AD-H4316-00
Required: 2
. NUT, BODY FITTING
Price unavailable
. SCREW, PAN HEAD
7
Yamaha Motors
. SCREW, PAN HEAD90157-04810
Required: 1
. SCREW, PAN HEAD
Price unavailable
. SPRING, SCREW
8
Yamaha Motors
. SPRING, SCREW5AD-H4332-00
Required: 1
. SPRING, SCREW
Price unavailable

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
