2000 Scooter YN50 - YN50 (5BV5) [010] CRANKSHAFT & PISTON diagram
![Yamaha Motors YN50 (5BV5) [010] - CRANKSHAFT & PISTON](https://cdn.crowleymarine.com/yamaha/Gupkd6Po.png)
1
Yamaha Motors
CRANKSHAFT ASSY4CU-E1400-00
Required: 1
CRANKSHAFT ASSY
Price unavailable
-15%
In stock
Only 1 remaining
$31.44
You save $5.55
-15%
3
Yamaha Motors
Woodruff Key90280-03017-00
Required: 1
KEY, WOODRUFF
$7.22
You save $1.27
-15%
4
Yamaha Motors
BEARING93306-204XK-00
Required: 2
BEARING
Supersedes: 93306-204X7-00
$35.69
You save $6.30
-15%
No longer availableSearch Nationwide Inventory
$9.34
You save $1.65
-15%
No longer availableSearch Nationwide Inventory
$9.34
You save $1.65
-15%
$14.87
You save $2.62
8
Yamaha Motors
PISTON (STD)5FV-E1631-00
Required: 1
PISTON (STD)
Price unavailable
-15%
8
Yamaha Motors
Piston (0.50MM O/S)3CP-11636-09-00
Required: 1
PISTON (0.50MM O/S)
Supersedes: 3CP-11636-00-00
$40.79
You save $7.20
-15%
9
Yamaha Motors
Piston Ring Set 2ND260-11601-22-00
Required: 1
. PISTON RING SET (0.50MM O/S)
Supersedes: 260-11610-22-00
$60.34
You save $10.65
9
Yamaha Motors
. PISTON RING SET (STD)5FV-E1610-00
Required: 1
. PISTON RING SET (STD)
Price unavailable
10
Yamaha Motors
. CIRCLIP93450-11818
Required: 2
. CIRCLIP
Price unavailable
11
Yamaha Motors
. PIN, PISTON5FX-E1633-00
Required: 1
. PIN, PISTON
Price unavailable
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
