2000 Scooter YN50 - YN50 (5ADT) [010] CARBURETOR diagram
![Yamaha Motors YN50 (5ADT) [010] - CARBURETOR](https://cdn.crowleymarine.com/yamaha/qGgSD5Az.png)
1
Yamaha Motors
CARBURETOR ASSY 15AD-14301-00
Required: 1
CARBURETOR ASSY 1
Price unavailable
2
Yamaha Motors
. DIAPHRAGM ASSY 25AD-14369-00
Required: 1
. DIAPHRAGM ASSY 2
Price unavailable
-15%
$8.07
You save $1.42
-50%
4
Yamaha Motors
THROTTLE VALVE SPRING1YU-14331-00-00
Required: 1
. SPRING, THROTTLE VALVE
In stock
Only 1 remaining
$3.50
You save $3.50
5
Yamaha Motors
. VALVE, THROTTLE 15AD-14312-30
Required: 1
. VALVE, THROTTLE 1
Price unavailable
-15%
6
Yamaha Motors
Float Chamber Gasket1YU-14384-00-00
Required: 1
. GASKET, FLOAT CHAMBER
$10.19
You save $1.80
7
Yamaha Motors
. AIR JET, MAIN14T-14337-00
Required: 1
. AIR JET, MAIN
Price unavailable
-15%
8
Yamaha Motors
THROTTLE SCREW SET1YU-14103-00-00
Required: 1
. SCREW, PILOT ADJUSTING
Supersedes: 367-14211-00-00
$29.74
You save $5.25
9
Yamaha Motors
. PIPE5AD-14197-00
Required: 1
. PIPE
Price unavailable
-15%
No longer availableSearch Nationwide Inventory
$5.09
You save $0.90
-15%
11
Yamaha Motors
Main Nozzle2XX-14341-00-00
Required: 1
. NOZZLE, MAIN
No longer availableSearch Nationwide Inventory
$16.57
You save $2.92
-15%
No longer availableSearch Nationwide Inventory
$4.67
You save $0.82
13
Yamaha Motors
. NEEDLE5AD-14336-00
Required: 1
. NEEDLE
Price unavailable
14
Yamaha Motors
. CLIP2T4-14137-00
Required: 1
. CLIP
Price unavailable
15
Yamaha Motors
. SEAT, SPRING2T4-14136-00
Required: 1
. SEAT, SPRING
Price unavailable
16
Yamaha Motors
. SPRING, PILOT ADJUSTING14T-14212-00
Required: 1
. SPRING, PILOT ADJUSTING
Price unavailable
-15%
17
Yamaha Motors
Air Screw Kit14T-14104-00-00
Required: 1
. SCREW, AIR ADJUSTING
Supersedes: 14T-14323-00-00
$10.19
You save $1.80
-15%
18
Yamaha Motors
CABLE ADJUSTMENT NUT85L-14161-00-00
Required: 1
. NUT, CABLE ADJUSTING
Supersedes: 288-14161-00-00
No longer availableSearch Nationwide Inventory
$8.07
You save $1.42
19
Yamaha Motors
. SCREW, WITH WASHER97901-05112
Required: 1
. SCREW, WITH WASHER
Price unavailable
20
Yamaha Motors
. SCREW, WITH WASHER97901-04116
Required: 2
. SCREW, WITH WASHER
Price unavailable
21
Yamaha Motors
. PIPE5AD-14349-00
Required: 1
. PIPE
Price unavailable
-15%
22
Yamaha Motors
Needle Valve2JA-14392-00-00
Required: 1
. VALVE, NEEDLE
$33.99
You save $6.00
-15%
$65.44
You save $11.55
-15%
24
Yamaha Motors
Float Pin14T-14386-00-00
Required: 1
. PIN, FLOAT
Supersedes: 1YU-14386-00-00
No longer availableSearch Nationwide Inventory
$11.04
You save $1.95
-50%
25
Yamaha Motors
Pan Head Screw98580-03006-00
Required: 1
. SCREW, PAN HEAD
Supersedes: 98501-03006-00
In stock
Only 2 remaining
$5.25
You save $5.25
-15%
26
Yamaha Motors
Air Screw Kit14T-14104-00-00
Required: 1
. SCREW, AIR ADJUSTING
Supersedes: 14T-14323-00-00
$10.19
You save $1.80
-15%
27
Yamaha Motors
Plunger Spring1YU-14335-00-00
Required: 1
. SPRING, PLUNGER
No longer availableSearch Nationwide Inventory
$8.07
You save $1.42
-15%
28
Yamaha Motors
STARTER PLUNGER1YU-14371-00-00
Required: 1
PLUNGER, STARTER
No longer availableSearch Nationwide Inventory
$18.69
You save $3.30
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
