1998 Scooter CW50 - CW50 (4VVF) [010] ELECTRICAL 1 diagram
![Yamaha Motors CW50 (4VVF) [010] - ELECTRICAL 1](https://cdn.crowleymarine.com/yamaha/RKMsnP5p.png)
-15%
1
Yamaha Motors
CDI UNIT ASSEMBLY3KJ-85540-10-00
Required: 1
C.D.I. UNIT ASSY
No longer availableSearch Nationwide Inventory
$100.29
You save $17.70
-15%
$72.24
You save $12.75
-15%
No longer availableSearch Nationwide Inventory
$36.74
You save $6.48
-15%
3
Yamaha Motors
YB4LB YUASA BATTERYYB4-LB000-00-00
Required: 1
BATTERY ASSY
Supersedes: 4SB-H2110-00-00
No longer availableSearch Nationwide Inventory
$25.49
You save $4.50
-15%
4
Yamaha Motors
Hose (3GG)90445-084J0-00
Required: 1
HOSE
Supersedes: 90445-083F2-00
$17.84
You save $3.15
-15%
5
Yamaha Motors
IGNITION COIL ASSY3KJ-82310-14-00
Required: 1
IGNITION COIL ASSY
Supersedes: 3KJ-82310-10-00
$35.69
You save $6.30
-15%
7
Yamaha Motors
TIPPING SCREW97707-60525-00
Required: 1
SCREW, TAPPING
$8.07
You save $1.42
-15%
8
Yamaha Motors
Plug Cap AssemblySPC-LB05F-00-00
Required: 1
PLUG CAP ASSY
Supersedes: 3WG-H2370-10-00
$24.64
You save $4.35
-15%
9
Yamaha Motors
Plug Cap Seal3WG-H2372-00-00
Required: 1
SEAL, PLUG CAP
$7.22
You save $1.27
10
Yamaha Motors
WIRE HARNESS ASSY3VL-H2590-10
Required: 1
WIRE HARNESS ASSY
Price unavailable
-15%
$3.02
You save $0.53
-15%
12
Yamaha Motors
Switch Cord Band4KH-H3936-01-00
Required: 2
BAND, SWITCH CORD
Supersedes: 4KH-H3936-00-00
$4.67
You save $0.82
-15%
13
Yamaha Motors
Oil Level Gauge Assembly53L-85720-10-00
Required: 1
OIL LEVEL GAUGE ASSY
Supersedes: 3VL-H5720-10-00
$55.24
You save $9.75
14
Yamaha Motors
SENDER UNIT ASSY, FUEL METER4VV-H5752-01
Required: 1
SENDER UNIT ASSY, FUEL METER
Price unavailable
-15%
16
Yamaha Motors
Bolt with Washer90119-05071-00
Required: 4
BOLT, WITH WASHER
$8.07
You save $1.42
-15%
No longer availableSearch Nationwide Inventory
$5.94
You save $1.05
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
