1992 Scooter CW50 - CW50 (4BX2) [999] FRAME diagram
![Yamaha Motors CW50 (4BX2) [999] - FRAME](https://cdn.crowleymarine.com/yamaha/fPIKHofz.png)
1
Yamaha Motors
FRAME COMP.4BX-F1110-00-11
Required: 1
FRAME COMP.
Price unavailable
-15%
$10.62
You save $1.87
-15%
$8.07
You save $1.42
-12%
4
Yamaha Motors
Engine Mounting Bolt2T4-21481-01-00
Required: 2
BOLT, ENGINE MOUNTING 1
$3.15
You save $0.45
-15%
5
Yamaha Motors
NUT95614-10100-00
Required: 2
NUT, U
Supersedes: 95611-10100-00
$7.22
You save $1.27
6
Yamaha Motors
ENGINE BRACKET COMP.3VL-F1410-10
Required: 1
ENGINE BRACKET COMP.
Price unavailable
-15%
7
Yamaha Motors
DAMPER 22T4-2139X-00-00
Required: 2
DAMPER
Supersedes: 2T4-2139X-01-00
No longer availableSearch Nationwide Inventory
$9.34
You save $1.65
8
Yamaha Motors
LABEL4BX-H2377-10
Required: 1
LABEL
Price unavailable
8
Yamaha Motors
MANUFACTURER PLATE4BX-F1182-10
Required: 1
MANUFACTURER PLATE
Price unavailable
-15%
8
Yamaha Motors
Compression Spring90501-290K2-00
Required: 2
SPRING, COMPRESSION
Supersedes: 90501-29517-00
No longer availableSearch Nationwide Inventory
$1.96
You save $0.35
8
Yamaha Motors
LABEL, EMISSION4BX-F111F-00
Required: 1
LABEL, EMISSION
Price unavailable
-15%
8
Yamaha Motors
BLIND RIVET90267-32071-00
Required: 2
RIVET, BLIND
Supersedes: 90267-32018-00
$1.87
You save $0.33
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
