1988 Scooter FS1 - FS1 (3EE1) [999] INTAKE diagram
![Yamaha Motors FS1 (3EE1) [999] - INTAKE](https://cdn.crowleymarine.com/yamaha/nvAaSs99.png)
1
Yamaha Motors
REED VALVE ASSY378-13610-61
Required: 1
REED VALVE ASSY
Price unavailable
-15%
2
Yamaha Motors
Reed Valve314-13613-01-00
Required: 1
. REED, VALVE
$36.54
You save $6.45
-15%
3
Yamaha Motors
REED VALVE STOPPER10X-13616-00-00
Required: 1
. STOPPER, REED VALVE
Supersedes: 314-13616-01-00
No longer availableSearch Nationwide Inventory
$12.74
You save $2.25
-15%
4
Yamaha Motors
Pan Head Screw98580-03008-00
Required: 2
. SCREW, PAN HEAD
Supersedes: 98501-03008-00
$3.27
You save $0.58
-15%
5
Yamaha Motors
Spring Washer92990-03100-00
Required: 2
. WASHER, SPRING
$8.07
You save $1.42
6
Yamaha Motors
GASKET, VALVE SEAT378-13621-60
Required: 1
GASKET, VALVE SEAT
Price unavailable
-15%
7
Yamaha Motors
98501-06014-0092501-06014-00
Required: 2
SCREW, PAN HEAD
No longer availableSearch Nationwide Inventory
$0.76
You save $0.14
8
Yamaha Motors
JOINT, PUMP3EE-13505-00
Required: 1
JOINT, PUMP
Price unavailable
9
Yamaha Motors
BOLT90109-06343
Required: 4
BOLT
Price unavailable
10
Yamaha Motors
COLLAR90387-17139
Required: 1
COLLAR
Price unavailable
11
Yamaha Motors
CASE, AIR CLEANER 15A3-14411-00
Required: 1
CASE, AIR CLEANER 1
Price unavailable
12
Yamaha Motors
ELEMENT, AIR CLEANER3E8-14451-00
Required: 1
ELEMENT, AIR CLEANER
Price unavailable
13
Yamaha Motors
GUIDE3E8-14473-00
Required: 1
GUIDE
Price unavailable
14
Yamaha Motors
STAY 13E8-14498-00
Required: 1
STAY 1
Price unavailable
-15%
15
Yamaha Motors
Pan Head Screw98580-06545-00
Required: 1
SCREW, PAN HEAD
Supersedes: 92503-06045-00
$5.52
You save $0.97
-20%
16
Yamaha Motors
Plate Washer92990-06600-00
Required: 1
WASHER, PLATE
Supersedes: 92901-06600-00
In stock
5+ in stock
$2.36
You save $0.59
17
Yamaha Motors
JOINT, AIR CLEANER 13E8-14453-00
Required: 1
JOINT, AIR CLEANER 1
Price unavailable
-15%
18
Yamaha Motors
TENSION SPRING90506-06106-00
Required: 1
SPRING, TENSION
$8.92
You save $1.57
19
Yamaha Motors
COVER 13E8-14417-00
Required: 1
COVER 1
Price unavailable
-20%
20
Yamaha Motors
Screw98580-04010-00
Required: 4
SCREW, PAN HEAD
In stock
Only 2 remaining
$7.59
You save $1.90
-15%
21
Yamaha Motors
Carburetor Cap288-14481-02-00
Required: 1
CAP, CARBURETOR
$22.09
You save $3.90
-15%
22
Yamaha Motors
TENSION SPRING90506-06261-00
Required: 1
SPRING, TENSION
Supersedes: 90506-06095-00
$8.92
You save $1.57
-15%
23
Yamaha Motors
DRAIN CLEANER257-15433-00-00
Required: 1
CLEANER, DRAIN
No longer availableSearch Nationwide Inventory
$17.84
You save $3.15
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
