1997 Maxi-Scooter YP250 - YP250 (4UC2) [010] LEG SHIELD diagram
![Yamaha Motors YP250 (4UC2) [010] - LEG SHIELD](https://cdn.crowleymarine.com/yamaha/GInx6D1V.png)
1
Yamaha Motors
LEG SHIELD ASSY4HC-28300-00
Required: 1
LEG SHIELD ASSY
Price unavailable
2
Yamaha Motors
COVER4HC-28365-00
Required: 1
COVER
Price unavailable
3
Yamaha Motors
HINGE4HC-21796-00
Required: 2
HINGE
Price unavailable
-15%
4
Yamaha Motors
Truss Screw97707-40612-00
Required: 2
SCREW, TAPPING
Supersedes: 97707-40512-00
$5.94
You save $1.05
-50%
In stock
Only 1 remaining
$0.50
You save $0.50
-15%
No longer availableSearch Nationwide Inventory
$0.62
You save $0.11
-20%
7
Yamaha Motors
Plate Washer90201-06M02-00
Required: 1
WASHER, PLATE
Supersedes: 90201-06008-00
In stock
Only 1 remaining
$2.12
You save $0.53
-15%
8
Yamaha Motors
Truss Screw97707-50012-00
Required: 4
SCREW, TAPPING
Supersedes: 90167-05025-00
$3.94
You save $0.69
-15%
9
Yamaha Motors
Truss Head Tapping Screw97707-50016-00
Required: 6
SCREW, TRUSS HEAD TAPPING
In stock
Only 4 remaining
$1.57
You save $0.28
10
Yamaha Motors
DAMPER4HC-28371-11
Required: 1
DAMPER
Price unavailable
11
Yamaha Motors
LID ASSY4HC-2478A-10
Required: 1
LID ASSY
Price unavailable
12
Yamaha Motors
LOCK ASSY 235R-21708-31
Required: 1
LOCK ASSY 2
Price unavailable
13
Yamaha Motors
PANEL, INNER 14HC-2836K-00
Required: 1
PANEL, INNER 1
Price unavailable
-50%
In stock
Only 1 remaining
$0.50
You save $0.50
15
Yamaha Motors
DAMPER, LOCATING 14HC-2836T-00
Required: 1
DAMPER, LOCATING 1
Price unavailable
-15%
16
Yamaha Motors
Truss Screw97707-50012-00
Required: 2
SCREW, TAPPING
Supersedes: 90167-05025-00
$3.94
You save $0.69
17
Yamaha Motors
BODY, COWLING4HC-28351-01-3H
Required: 1
BODY, COWLING
Price unavailable
17
Yamaha Motors
BODY, COWLING4HC-28351-01-4B
Required: 1
BODY, COWLING
Price unavailable
17
Yamaha Motors
BODY, COWLING4HC-28351-01-P1
Required: 1
BODY, COWLING
Price unavailable
17
Yamaha Motors
BODY, COWLING4HC-28351-01-P0
Required: 1
BODY, COWLING
Price unavailable
-15%
18
Yamaha Motors
Nut25G-21535-00-00
Required: 4
NUT 1
Supersedes: 3VP-21535-00-00
$8.07
You save $1.42
-50%
In stock
Only 1 remaining
$0.50
You save $0.50
-15%
In stock
Only 5 remaining
$6.37
You save $1.12
-15%
21
Yamaha Motors
Bolt with Washer90119-06226-00
Required: 2
BOLT, WITH WASHER
Supersedes: 90119-06060-00
$2.38
You save $0.42
-15%
$2.63
You save $0.47
-15%
23
Yamaha Motors
Truss Head Tapping Screw97707-50016-00
Required: 5
SCREW, TRUSS HEAD TAPPING
In stock
Only 4 remaining
$1.57
You save $0.28
-15%
24
Yamaha Motors
TAPPING SCREW90163-05006-00
Required: 4
SCREW, TAPPING
$2.98
You save $0.52
25
Yamaha Motors
PANEL, INNER 24HC-2836L-00
Required: 1
PANEL, INNER 2
Price unavailable
-15%
26
Yamaha Motors
Truss Screw97707-50012-00
Required: 2
SCREW, TAPPING
Supersedes: 90167-05025-00
$3.94
You save $0.69
-15%
27
Yamaha Motors
Truss Screw97707-50012-00
Required: 2
SCREW, TAPPING
Supersedes: 90167-05025-00
$3.94
You save $0.69
28
Yamaha Motors
SCREEN4HC-2837U-00
Required: 1
SCREEN
Price unavailable
29
Yamaha Motors
TRIM4EJ-28376-00
Required: 1
TRIM
Price unavailable
-14%
30
Yamaha Motors
PLASTIC SCREW90150-05024-00
Required: 6
SCREW, ROUND HEAD
$2.89
You save $0.46
31
Yamaha Motors
MOLE 14HC-28345-00-7B
Required: 1
MOLE 1
Price unavailable
-50%
In stock
Only 1 remaining
$0.50
You save $0.50
-15%
No longer availableSearch Nationwide Inventory
$4.67
You save $0.82
-15%
34
Yamaha Motors
Truss Screw97707-50012-00
Required: 4
SCREW, TAPPING
Supersedes: 90167-05025-00
$3.94
You save $0.69
35
Yamaha Motors
COVER, UNDER4HC-28385-11
Required: 1
COVER, UNDER
Price unavailable
-50%
In stock
Only 1 remaining
$0.50
You save $0.50
37
Yamaha Motors
EMBLEM4HC-28315-00
Required: 1
EMBLEM
Price unavailable
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
