2017 International 130hp - F130AETX (6EM3) [070] ELECTRICAL 6 diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status

Click on

to see part

Ships Now

Ships Later

Out of Stock

Yamaha Motors F130AETX (6EM3) [070] - ELECTRICAL 6

Change View:

-15%

Yamaha Motors

SENSOR, WATER PRES6AW-8366B-10-00

Required: 1

SENSOR, WATER PRESSURE

Supersedes: 6AW-8366B-01-00

~~$230.50~~

$195.95

You save $34.55

More details

-15%

Yamaha Motors

Input Adaptor60V-8366D-00-00

Required: 1

ADAPTOR, INPUT

~~$74.99~~

$63.74

You save $11.25

-20%

BOLT

~~$2.70~~

$2.16

You save $0.54

-20%

CLAMP

Supersedes: 90465-11M10-00

2 aftermarket alternatives

In stock

5+ in stock

~~$2.80~~

$2.24

You save $0.56

More details

-15%

Yamaha Motors

HOSE - WITH SPRING90447-07010-00

Required: 1

HOSE, WITH SPRING (L520)

~~$3.99~~

$3.39

You save $0.60

-15%

SEAL

~~$4.60~~

$3.91

You save $0.69

More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
