1982 Two-Stroke Outboard 35 - DT35 HANDLE diagram
-15%
1
Suzuki Marine
Obsolete Suzuki Part63121-94302-01J
Required: 1
COVER, TILLER HANDLE COVER, TILLER HANDLE
No longer availableSearch Nationwide Inventory
$25.48
You save $4.50
-20%
2
Suzuki Marine
SPACER,HANDLE C63114-95L00
Required: 1
SPACER SPACER
Supersedes: 63114-94300
$5.17
You save $1.29
-15%
3
Suzuki Marine
BOLT STUD09108-08147
Required: 2
STUD BOLT STUD BOLT
Supersedes: 09108-08036
$6.74
You save $1.19
-20%
4
Suzuki Marine
WASHER LOCK09162-08007
Required: 2
LOCK WASHER LOCK WASHER
Supersedes: 09162-08003
$1.50
You save $0.38
-20%
5
Suzuki Marine
Nut09140-08023-XC0
Required: 2
NUT NUT
Supersedes: 09140-08003
$2.30
You save $0.58
-15%
6
Suzuki Marine
Obsolete Suzuki Part63215-93401
Required: 1
MARK, HANDLE GRIP MARK, HANDLE GRIP
Supersedes: 63215-93410
No longer availableSearch Nationwide Inventory
$1.01
You save $0.18
-20%
6
Suzuki Marine
MARK,HANDLE GRI63215-93400
Required: 1
MARK, HANDLE GRIP MARK, HANDLE GRIP
In stock
Only 2 remaining
$1.95
You save $0.49
-15%
7
Suzuki Marine
Supersedes to 63111-93402-02M63111-93402-01J
Required: 1
HANDLE, TILLER HANDLE, TILLER
Supersedes: 63111-93401-01J
No longer availableSearch Nationwide Inventory
$31.77
You save $5.61
-15%
8
Suzuki Marine
Obsolete Suzuki Part09160-32004
Required: 2
WASHER (32.5x42x0.2) WASHER (32.5x42x0.2)
No longer availableSearch Nationwide Inventory
$1.99
You save $0.35
-15%
9
Suzuki Marine
Obsolete Suzuki Part09164-32001
Required: 1
WAVE WASHER WAVE WASHER
No longer availableSearch Nationwide Inventory
$1.98
You save $0.35
-15%
10
Suzuki Marine
Obsolete Suzuki Part09160-32007
Required: 1
WASHER (32.5x42x0.2) WASHER (32.5x42x0.2)
No longer availableSearch Nationwide Inventory
$2.15
You save $0.38
-15%
11
Suzuki Marine
Obsolete Suzuki Part63117-93400
Required: 1
PROTECTOR, STOP SWITCH WIRE PROTECTOR, STOP SWITCH WIRE
No longer availableSearch Nationwide Inventory
$1.60
You save $0.28
-15%
12
Suzuki Marine
GROMMET,THROTTL63625-96301
Required: 1
GROMMET GROMMET
Supersedes: 09309-05008
$2.35
You save $0.42
-15%
13
Suzuki Marine
CLAMP(L:80)09404-06036
Required: 1
CLAMP CLAMP
Supersedes: 09404-06404
$1.87
You save $0.33
-15%
13
Suzuki Marine
Supersedes to 09404-0642609404-06415
Required: 1
CLAMP CLAMP
Supersedes: 09404-06414
No longer availableSearch Nationwide Inventory
$0.76
You save $0.14
13
Suzuki Marine
CLAMP CLAMP09404-06403
Required: 1
CLAMP CLAMP
Price unavailable
-15%
13
Suzuki Marine
CLAMP(L:65)09404-06039
Required: 1
CLAMP CLAMP
Supersedes: 09404-06413
$1.83
You save $0.32
-20%
14
Suzuki Marine
CABLEASSY,THROT63610-96302
Required: 2
CABLE, THROTTLE (GRIP->LEVER) CABLE, THROTTLE (GRIP->LEVER)
Supersedes: 63610-94300
In stock
Only 1 remaining
$17.64
You save $4.41
-50%
15
Suzuki Marine
SCREW 6X12 (SUS09125-06069
Required: 1
SCREW SCREW
Supersedes: 09125-06033
In stock
Only 1 remaining
$1.20
You save $1.20
-15%
16
Suzuki Marine
Obsolete Suzuki Part63222-93200
Required: 1
DRUM, HANDLE ROD DRUM, HANDLE ROD
No longer availableSearch Nationwide Inventory
$27.47
You save $4.85
-20%
17
Suzuki Marine
BUSH63225-93200
Required: 2
BUSHING BUSHING
In stock
Only 1 remaining
$3.71
You save $0.93
-15%
18
Suzuki Marine
Obsolete Suzuki Part63241-94300
Required: 1
ADJUSTER, GRIP ADJUSTER, GRIP
No longer availableSearch Nationwide Inventory
$3.48
You save $0.61
-20%
19
Suzuki Marine
WASHER09160-06082
Required: 1
WASHER (6.5x13x1) WASHER (6.5x13x1)
Supersedes: 09160-06015
In stock
Only 1 remaining
$1.42
You save $0.36
-15%
20
Suzuki Marine
WASHER09162-06006
Required: 1
LOCK WASHER LOCK WASHER
Supersedes: 09162-06001
$1.60
You save $0.28
-15%
21
Suzuki Marine
BOLT09100-06113
Required: 1
BOLT (6x16) BOLT (6x16)
Supersedes: 09100-06019
$2.07
You save $0.36
-15%
21
Suzuki Marine
BOLT09100-06122
Required: 1
BOLT (6x20) BOLT (6x20)
Supersedes: 09100-06020
No longer availableSearch Nationwide Inventory
$1.11
You save $0.20
-15%
22
Suzuki Marine
SPRING,HANDLE L09440-12027
Required: 1
SPRING SPRING
Supersedes: 63226-93200
In stock
Only 1 remaining
$1.34
You save $0.24
-15%
23
Suzuki Marine
PIN09205-03004
Required: 1
PIN, HANDLE ROD (L:20) PIN, HANDLE ROD (L:20)
$1.31
You save $0.23
-15%
24
Suzuki Marine
Obsolete Suzuki Part63221-93400
Required: 1
ROD, HANDLE (MODEL G,J) ROD, HANDLE (MODEL G,J)
No longer availableSearch Nationwide Inventory
$13.47
You save $2.38
-15%
24
Suzuki Marine
Supersedes to 63220-9430263220-94301
Required: 1
ROD, HANDLE (MODEL VZ) ROD, HANDLE (MODEL VZ)
Supersedes: 63220-94300
No longer availableSearch Nationwide Inventory
$13.22
You save $2.33
-20%
25
Suzuki Marine
HANDLE ROD PIN63227-93200
Required: 1
PIN, HANDLE ROD (L:14) PIN, HANDLE ROD (L:14)
$1.99
You save $0.50
-20%
26
Suzuki Marine
STOPPER,HANDLE63223-92D00
Required: 1
STOPPER STOPPER
Supersedes: 63223-93200
In stock
Only 1 remaining
$4.11
You save $1.03
-15%
27
Suzuki Marine
WASHER09163-06001
Required: 1
LOCK WASHER LOCK WASHER
In stock
Only 1 remaining
$1.60
You save $0.28
-20%
28
Suzuki Marine
Screw (M8 X 40)09126-06006
Required: 1
SCREW (6x20) SCREW (6x20)
Supersedes: 09126-06004
In stock
Only 5 remaining
$1.72
You save $0.43
-20%
29
Suzuki Marine
GRIP COMP,HANDL63210-93E30
Required: 1
GRIP, HANDLE GRIP, HANDLE
Supersedes: 63210-93200
$31.92
You save $7.98
-15%
30
Suzuki Marine
RELEASE SCREW C09250-25001
Required: 1
CAP, SWITCH CAP, SWITCH
$2.27
You save $0.40
-15%
31
Suzuki Marine
CAP,THROTTLE CA63625-94301
Required: 1
CAP, CABLE CAP, CABLE
Supersedes: 63625-94300
$2.56
You save $0.45
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
