Pre 1997 Marine Engine BF - BF40D LHA OIL PUMP diagram
-15%
001
Honda
PUMP ASSY., OIL15100-ZV5-000
Required: 1
PUMP ASSY., OIL
$258.11
You save $45.55
-15%
002
Honda
COVER, OIL PUMP15116-ZV5-000
Required: 1
COVER, OIL PUMP
$30.55
You save $5.39
-15%
003
Honda
ROTOR (INNER)15122-ME5-000
Required: 1
ROTOR (INNER)
$13.44
You save $2.37
-15%
004
Honda
SHAFT, OIL PUMP15132-ZV5-000
Required: 1
SHAFT, OIL PUMP
$18.31
You save $3.23
-15%
005
Honda
ROTOR A (OUTER)15162-393-000
Required: 1
ROTOR A (OUTER)
$20.38
You save $3.60
-15%
006
Honda
VALVE, RELIEF15231-413-020
Required: 1
VALVE, RELIEF
$23.20
You save $4.10
-15%
007
Honda
SPRING, RELIEF VALVE15232-KT8-000
Required: 1
SPRING, RELIEF VALVE
$4.27
You save $0.75
-15%
008
Honda
BOLT, SEALING (14MM)15236-ZV5-010
Required: 1
BOLT, SEALING (14MM)
$5.58
You save $0.98
-15%
009
Honda
WASHER (14MM)15302-PE0-300
Required: 1
WASHER, SEALING (14MM)
$6.99
You save $1.23
010
Honda
BOLT, FLANGE (6X55)90147-ZW4-000
Required: 4
BOLT, FLANGE (6X55)
Price unavailable
-15%
011
Honda
SCREW, PAN (6X16)90084-ZZ5-M00
Required: 3
SCREW, PAN (6X16)
$1.16
You save $0.20
-15%
012
Honda
WASHER (13MM)90456-MC7-000
Required: 1
WASHER, THRUST (13MM)
$2.82
You save $0.50
013
Honda
O-RING, PUMP COVER91301-ZV5-000
Required: 1
O-RING, PUMP COVER
Price unavailable
-15%
013
Honda
O-RING, PUMP COVER91301-ZV5-010
Required: 1
O-RING, PUMP COVER
$5.54
You save $0.98
-15%
014
Honda
O-RING (54X2.4)91302-KF0-003
Required: 1
O-RING (54X2.4) (ARAI)
$3.94
You save $0.70
-15%
015
Honda
ROLLER (5X17.8)96220-50178
Required: 1
ROLLER (5X17.8)
$0.85
You save $0.15
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
