• Blue Sea Systems 2135; Circuit Breaker 25A, Push Button Reset

Blue Sea Systems 2135; Circuit Breaker 25A, Push Button Reset

    • MPN: 2135
    • SKU : LNS-661-2135
    • Price: $12.50
    • Cross Ship:84 At Manufacturer (Received by us in 4 days , then ships to you)
ESTIMATE SHIPPING: Add parts, then click "My Cart" at top of screen to see "Estimate Shipping Charges & Processing Times" tool.

Description:

Circuit Breaker 25A, Push Button Reset

Provides economical circuit protection for 3 to 40 Amp loads when switching is provided separately. Compact design enables high density circuit protection configurations - waterproof with optional boot. Trip free - cannot be held closed after trip.
Interrupting Capacity: 3,000A @ 14.7V DC / 2,500A @ 28V DC
Voltage Max. Operating: 32V DC
Temperature Min. Operating: -10°C
Temperature Max. Operating: 60°C
Type: Thermal trip, manual reset
Terminals: 8 Screw Terminals or 1/4" Male Quick Connect Terminals
Screw Terminal Torque: 6 in-lb max.
Amps: 25
Note: Please make sure repair parts fit your vehicle before purchasing. Check our parts diagrams, catalogs or contact us.
